Pressurization

In pressurization applications, micro magnetic gear pumps are designed to provide more pressure to a liquid. This is particularly useful when the existing line pressure is insufficient for system requirements, such as with water lines, or when handling other fluids stored in tanks at atmospheric or lower-than-needed pressures. These pumps draw fluid from such low-pressure sources and boost it to the required higher pressure level. As positive displacement pumps, they move a fixed volume of fluid with each operating cycle, enabling them to reliably build and maintain system pressure.

Our gear pump series covers a flow range of 0-65 L/min. Depending on operating conditions and the characteristics of the conveyed fluid, the pump body can withstand pressures of 20-300 Bar.

All gear pumps deliver smooth, pulsation-free, and precise positive displacement pumping across a broad temperature range (-120 to 150°C) and viscosity range (0.2 to 20,000 cps).

Availability:



Inquire

Unlock Exclusive Solutions And Get Immediate Access To Professional Support!

More Information

Typical Application Scenarios:
✅ Pharmaceuticals & Medical: Drug delivery, infusion pumps, dialysis machines.
✅ Laboratory Equipment: Precise liquid handling and chemical reagent delivery.
✅ Analytical Instruments: Mobile phase delivery for chromatographic and mass spectrometric analysis.
✅ Food & Beverage Processing: Precise liquid dispensing and delivery.
✅ Cosmetics Manufacturing: Accurate ingredient dosing and product filling.
✅ Environmental Monitoring: Water sample collection and analysis.
✅ Industrial Automation: Precise liquid control and delivery in production lines.
✅ Printing and Coating: Precise ink or paint delivery.
✅ Semiconductor Manufacturing: Precision delivery and handling of chemicals.
✅ Automotive Industry: Fuel delivery and cooling systems.

Product Advantages
1. Specialized Gear Tooth Profile Design
Our proprietary gear tooth profile design delivers outstanding wear resistance and achieves near-pure rolling gear meshing.
2. Optimized Cavity Profile Design
The pump adapts reliably to widely varying outlet pressure conditions, performing excellently under low pressure, high pressure, or even brief reverse pressure scenarios.
3. Pulsation-Free Outlet Pressure
High-precision component machining and structural design ensure exceptionally smooth and stable fluid transfer.
4. Injection-Molded Gears
The gear working faces are formed using a high-precision, single-step injection molding process without subsequent machining, guaranteeing optimal surface integrity and performance.
5. High-Precision Ceramic Shafts
Equipped with high-precision ceramic shafts that offer exceptional wear resistance and rigidity, ensuring reliable pump operation with abrasive liquids and under high-pressure conditions.
6. Extended Dry Running and Self-Priming
In applications requiring the pump to create vacuum for fluid intake, the NP Series provides dependable performance and can tolerate extended dry-running periods.
7. Multiple Motor Options
A wide range of motor options is available, including: Explosion-Proof AC, Variable Frequency AC, Single-Phase / Three-Phase AC, Brushed DC, Brushless DC, Brushless DC with built-in drive, and Shielded Brushless DC with integrated drive.

For more general information on gear pumps, click "More Info"

Pumps	Flow Range	Differential Pressure	Pump Body Pressure Rating	More
20 Series	0-1.50L/min	20Bar	40bar	More Info
42 Series	0-2.20L/min	20Bar	20-150Bar	More Info
51 Series	0-6.00L/min	20Bar	20-150Bar	More Info
60 Series	0-10.5L/min	20Bar	40-300Bar	More Info
98 Series	0-55.0L/min	20Bar	40-300Bar	More Info
106 Series	0-65.0L/min	20Bar	40-150Bar	More Info

By offering multiple contact material options and shaft seal configurations, we tailor the optimal solution for your specific application. Contact us today to discuss your requirements.
