Atomization

In the atomization function, micro magnetic gear pumps excel at converting liquids into tiny droplets, forming a fine mist or aerosol. This is achieved by supplying a stable, pressure-controlled liquid stream to a nozzle or atomizer. The pump's consistent pressure output is crucial for forming uniform and fine mist droplets, ensuring the liquid is uniformly dispersed in the air. This makes it suitable for various applications requiring precise and consistent aerosol generation. In some high-speed centrifugal atomizers, the gear mechanism itself can also be utilized to achieve the high-speed rotation of the atomizing disk.

Our gear pump series covers a flow range of 0-65 L/min. Depending on operating conditions and the characteristics of the conveyed fluid, the pump body can withstand pressures of 20-300 Bar.

All gear pumps deliver smooth, pulsation-free, and precise positive displacement pumping across a broad temperature range (-120 to 150°C) and viscosity range (0.2 to 20,000 cps).

Availability:



Inquire

Unlock Exclusive Solutions And Get Immediate Access To Professional Support!

More Information

Typical Application Scenarios:
✅ Industrial Coating: Uniform spray application of paints and coatings.
✅ Humidification Systems: Regulating environmental humidity.
✅ Disinfection Spraying: Area disinfection and air purification.
✅ Pharmaceutical Industry: Spray drying for powder drug production.
✅ Agriculture: Precision spraying of pesticides and fertilizers.
✅ Air Conditioner Cooling: Cooling treatment for external units.
✅ Laboratory Research: Precise reagent delivery and sample preparation for analytical processes.

Product Features

Product Feature	Specification
Flow Range	0.1 ml/rev - 26 ml/rev (1 ml/min - 65000 ml/min)
Pressure Differential	20-40 Bar(Customizable)
Pressure Rating	20-300 Bar(Customizable)
Operating Speed	1-4000 rpm
Operating Temperature	-120 to 150 °C
Conveying liquid viscosity range	0.2~10,000cps, Capable of handling gas-liquid two-phase viscosity
Metering Accuracy	Up to 0.1%
Lifespan & Reliability	Long service life, capable of continuous operation for 20,000 hours
Operational Characteristics	Stable, pulsation-free flow, Low noise operation
Dry Running Capability	Up to 100 hours under suitable conditions
Inlet Vacuum	-0.85 Bar (Speed dependent)
Sealing Technology	Magnetic drive, ensuring completely leak-free operation

For more general information on gear pumps, click "More Info"

Pumps	Flow Range	Differential Pressure	Pump Body Pressure Rating	More
20 Series	0-1.50L/min	20Bar	40bar	More Info
42 Series	0-2.20L/min	20Bar	20-150Bar	More Info
51 Series	0-6.00L/min	20Bar	20-150Bar	More Info
60 Series	0-10.5L/min	20Bar	40-300Bar	More Info
98 Series	0-55.0L/min	20Bar	40-300Bar	More Info
106 Series	0-65.0L/min	20Bar	40-150Bar	More Info

By offering multiple contact material options and shaft seal configurations, we tailor the optimal solution for your specific application. Contact us today to discuss your requirements.
