Choosing the right hydraulic component can feel overwhelming, especially when two options look similar on paper. If you are debating between a gear pump and a gerotor pump, you are likely looking for the best way to move fluid efficiently under specific conditions. While both belong to the positive displacement family, their internal geometries create vast differences in performance, sound, and longevity.
Whether you need a solution for high pressure industrial tasks or a low noise pump for a passenger vehicle, understanding these mechanical nuances is key to your project's success.
The most fundamental difference lies in how they move fluid. A standard hydraulic gear pump (specifically the external type) uses two identical gears meshing together. One gear drives the other. As they unmesh at the inlet, they create a vacuum that pulls fluid in, carrying it around the outside of the gears to the outlet.
A gerotor pump is a bit different. It is essentially an internal gear pump variant. It consists of an inner rotor and an outer rotor. The inner rotor has one fewer tooth than the outer one. As they rotate together, the changing volume between the teeth creates the pumping action. This "generated rotor" (gerotor) geometry allows for a very compact footprint compared to the side-by-side arrangement of traditional precision gear pumps.
External Design: Requires more lateral space because the gears sit side-by-side.
Gerotor Design: Concentric. It sits on the shaft, making it perfect for tight engine compartments.
Simplicity: Both designs use few moving parts, which keeps maintenance costs low for both gear pump types.
When your application demands high pressure, the external gear pump is usually the champion. Its design allows for robust housing—often made from aluminum hydraulic alloys or cast iron—that can withstand significant internal force. These units frequently operate at pressures exceeding 3,000 PSI (approximately 210 bar).
Gerotor pumps generally struggle in these high-force environments. Because they rely on the sliding contact of the rotor teeth over a larger surface area, internal leakage (slippage) increases as pressure rises. They are most comfortable in low to medium pressure roles, such as engine lubrication or cooling circuits. If you try to push a gerotor into a high pressure industrial press role, you will likely see a rapid drop in efficiency.
| Feature | Standard Gear Pump (External) | Gerotor Pump |
| Max Pressure Range | Up to 250+ bar | Typically under 100 bar |
| Housing Material | Aluminum hydraulic or Steel | Sintered Metal or Steel |
| Efficiency at High PSI | High | Low (due to internal slip) |
If you are designing a system for laboratory use or a luxury car, sound matters. This is where the gerotor shines. Because the teeth in a gerotor slide into each other with a high contact ratio, the fluid delivery is much smoother. This results in low noise operation and minimal pressure pulsation.
Traditional gear pumps are notorious for being loud. The meshing of teeth can create a "whine" at high speeds. While manufacturers have developed low noise versions of the external gear pump by using helical gears or special tooth profiles, they rarely match the inherent quietness of a gerotor.
Contact Ratio: Gerotors have more teeth in contact at once, spreading the load.
Fluid Trapping: External gears can trap fluid at the mesh point, causing "pressure spikes" that create noise; gerotors avoid this via their smooth internal geometry.
Speed: At high RPMs, the vibration in a standard gear pump becomes much more pronounced.
How do these pumps handle "thick" fluids? Both are excellent for high viscosity liquids compared to centrifugal pumps, but they behave differently as the fluid thickens.
A precision gear pump is often the go-to for resins, polymers, and thick oils. The large gaps between the gear teeth allow them to "scoop" heavy fluids effectively. We often see these used in chemical processing where high viscosity handling is a daily requirement.
While gerotors handle oil well, they have tighter internal clearances. If the fluid is too thick, it may not fill the chambers fast enough at high speeds, leading to cavitation. However, for mid-range oils, the gerotor’s smooth action ensures the fluid isn't "sheared" as aggressively as it might be in an external gear pump.
In a perfect world, hydraulic fluid is always clean. In the real world, it isn't. The gear pump is legendary for its ruggedness. Because it often uses aluminum hydraulic bushings that can "absorb" minor particles, it can survive in environments that would kill other pumps.
Gerotors are more sensitive. Since the rotors often rely on the fluid itself for lubrication between the sliding tooth surfaces, dirty fluid acts like sandpaper. Small contaminants can quickly score the rotors, leading to a loss of the tight seal required for the pump to work.
Gear Pump: Better for "dirty" industrial systems; easy to rebuild.
Gerotor: Best for "closed" systems (like engines) where oil is filtered constantly.
Materials: Aluminum hydraulic bodies help with heat dissipation in both, but steel rotors are standard for wear resistance.
Choosing between these two often comes down to the specific "job description" of the machine.
We see the external gear pump in heavy machinery. Think of tractors, forklifts, and industrial power units. Its ability to provide high pressure and its compatibility with aluminum hydraulic components makes it cost-effective and powerful. It is the "workhorse" of the hydraulic world.
Gerotors are the "silent partners." You will find them inside your car's engine pumping oil, or in small, compact transmissions. They are also popular for laboratory equipment where a small, low noise footprint is more important than raw pressure.
Efficiency isn't just one number. We have to look at how much fluid "slips" back to the inlet.
In a precision gear pump, manufacturers use "wear plates" that press against the sides of the gears. This keeps the seal tight even as the pump wears down. This allows the gear pump to maintain high volumetric efficiency over a long life.
Gerotors have higher mechanical friction because of the sliding contact. However, at low pressures, their volumetric efficiency is quite good. The problem arises when the pressure increases; the lack of side-loading compensation means they lose efficiency faster than a high-quality external gear pump.
The choice between a gear pump and a gerotor pump isn't about which is "better," but which fits your constraints.
Choose an external gear pump if you need high pressure, rugged durability, and a cost-effective solution for industrial or mobile hydraulics. It is the king of high viscosity and tough environments.
Choose a gerotor pump if you need low noise, a compact and concentric design, and are operating at lower pressures. It is the perfect fit for laboratory settings or automotive lubrication.
Both designs have stood the test of time. By matching their strengths—the pressure of the gear pump or the quietness of the gerotor—to your specific needs, you ensure a reliable and efficient system.
Q: Can a gear pump run dry?A: No. Both gear pumps and gerotors rely on the pumped fluid for lubrication and cooling. Running them dry will cause rapid heat buildup and galling of the aluminum hydraulic or steel parts.
Q: Why are gear pumps often made of aluminum?A: Aluminum hydraulic housings offer a great balance of weight reduction and heat dissipation. They are also "forgiving" to the gears during the initial break-in period.
Q: Is a gerotor considered a type of internal gear pump?A: Yes. It is a specific variation of the internal gear pump that lacks the "crescent" shaped separator found in other internal designs.
Q: Which is easier to repair?A: Generally, the external gear pump is easier to service. You can often replace the bushings and seals easily. Gerotors are often replaced as a complete rotor set because the wear is spread across the entire tooth profile
