Metering Gear Pump for Precision Fluid Transfer

The measurement function of micro magnetic gear pumps involves the precise control and transfer of minute liquid volumes, ensuring highly consistent fluid delivery with each cycle. The gear pump operates through two tightly meshed gears (driving and driven) rotating within a pump chamber, creating sealed cavities that displace fluid with high accuracy. This precision is critical for applications requiring strict proportional dosing.

Our gear pump series covers a flow range of 0-65 L/min. Depending on operating conditions and the characteristics of the conveyed fluid, the pump body can withstand pressures of 20-300 Bar.

All gear pumps deliver smooth, pulsation-free, and precise positive displacement pumping across a broad temperature range (-120 to 150°C) and viscosity range (0.2 to 20,000 cps).

Availability:



Inquire

Unlock Exclusive Solutions And Get Immediate Access To Professional Support!

More Information

Metering Gear Pump for Accurate Liquid Dosing

A Metering Gear Pump is designed for applications that require accurate liquid dosing, stable flow output and repeatable precision fluid transfer. By using a positive displacement gear structure, the pump can deliver a fixed volume of liquid with each rotation, making it suitable for systems where consistent metering accuracy is required.

Suofu Micro Magnetic Gear Pump solutions are widely used as gear dosing pumps for precision fluid measurement, chemical dosing, reagent delivery, laboratory testing and industrial fluid control. The stable and pulsation-free flow helps improve dosing accuracy and reduce liquid transfer variation in continuous or intermittent operation.

Typical Application Scenarios of Metering Gear Pump:

✅ Pharmaceuticals & Medical: Precise dispensing of pharmaceuticals and nutritional solutions.

✅ Chemical Production: Accurate addition of chemical additives or catalysts.

✅ Laboratory Research: Reagent addition and sample preparation for experiments.

✅ Food & Beverage: Precision ingredient and flavorant dosing.

Product Features of Metering Gear Pump

Product Feature	Specification
Flow Range	0.1 ml/rev - 26 ml/rev (1 ml/min - 65000 ml/min)
Inlet/outlet Pressure Differential	20-40 Bar(Customizable)
Pressure Rating	20-300 Bar(Customizable)
Operating Speed	1-4000 rpm
Operating Temperature	-120 to 150 °C
Conveying liquid viscosity range	0.2~10,000cps, Capable of handling gas-liquid two-phase viscosity
Metering Accuracy	Up to 0.1%
Lifespan & Reliability	Long service life, capable of continuous operation for 20,000 hours
Operational Characteristics	Stable, pulsation-free flow, Low noise operation
Dry Running Capability	Up to 100 hours under suitable conditions
Inlet Vacuum	-0.85 Bar (Speed dependent)
Sealing Technology	Magnetic drive, ensuring completely leak-free operation

For more general information on Micro Gear Pump Solutions

Pumps	Flow Range	Differential Pressure	Pump Body Pressure Rating	More
20 Series	0-1.50L/min	20Bar	40bar	More Info
42 Series	0-2.20L/min	20Bar	20-150Bar	More Info
51 Series	0-6.00L/min	20Bar	20-150Bar	More Info
60 Series	0-10.5L/min	20Bar	40-300Bar	More Info
98 Series	0-55.0L/min	20Bar	40-300Bar	More Info
106 Series	0-65.0L/min	20Bar	40-150Bar	More Info

Why Use a Gear Dosing Pump for Precision Fluid Measurement?

A Gear Dosing Pump provides accurate and repeatable liquid delivery by controlling pump speed and gear displacement. Compared with general transfer pumps, a Metering Gear Pump is more suitable for applications that require fixed-volume dosing, proportional liquid addition and continuous precision fluid measurement.

For chemical additives, catalysts, reagents, nutritional solutions, flavorings or special industrial liquids, the gear dosing pump can provide stable flow output and better process control. This makes the Micro Magnetic Gear Pump a reliable choice for customers who need high metering accuracy, compact structure and long-term stable operation.

Custom Gear Dosing Pump Solutions

Suofu provides customized Gear Dosing Pump solutions for customers who need accurate precision fluid measurement and stable liquid transfer. According to different working conditions, the Metering Gear Pump can be customized in pump material, sealing structure, motor configuration, flow range and connection type.

Whether you need a Micro Magnetic Gear Pump for chemical dosing, a precision metering pump for laboratory equipment, or a gear dosing pump for industrial fluid control systems, Suofu can provide pump selection support and customized solutions.

FAQ About Metering Gear Pump

What is a Metering Gear Pump?

A precision gear metering pump is a positive displacement pump used for accurate liquid dosing and precision fluid transfer. It delivers liquid through rotating gears and provides stable flow output for metering applications.

What is the difference between a gear dosing pump and a general transfer pump?

A gear dosing pump focuses on accurate and repeatable liquid delivery, while a general transfer pump is mainly used for moving liquid in larger volumes. For precision fluid measurement, a Metering Gear Pump is usually more suitable.

What liquids can a Micro Magnetic Gear Pump handle?

A Micro Magnetic Gear Pump can be used for many low-viscosity and medium-viscosity liquids, including reagents, additives, chemicals, nutritional solutions, flavorings and industrial fluids. The final selection should be based on viscosity, temperature, pressure and material compatibility.

Is this Metering Gear Pump suitable for continuous operation?

Yes. Suofu Metering Gear Pump solutions are designed for stable fluid transfer and can be used in continuous or intermittent operation according to the application requirements.

Can Suofu provide customized Metering Gear Pump solutions?

Yes. Suofu can provide customized Gear Dosing Pump solutions based on flow rate, pressure, liquid properties, material requirements, motor type and installation conditions.

By offering multiple contact material options and shaft seal configurations, we tailor the optimal solution for your specific application. Contact us today to discuss your requirements.
